Stent Spec Table

Model No.	Nominal Stent Length L (mm)	Nominal Stent Diameter Φ (mm)	Outer Diameter (OD)at Free Expansion (mm)	Recommended Target Vessel Diameter (mm)	Tip Shape	Compatible Microcatheter Diameter (inch)
CY-25-14	14	2.5	3.0	≥ 2.0 & <2.5	Straight	0.017
CY-25-14NT	14	2.5	3.0	≥ 2.0 & <2.5	Curved 45°
CY-25-20	20	2.5	3.0	≥ 2.0 & <2.5	Straight
CY-25-20NT	20	2.5	3.0	≥ 2.0 & <2.5	Curved 45°
CY-35-14	14	3.5	4.0	≥ 2.5 & <3.5	Straight
CY-35-14NT	14				Curved 45°
CY-35-20	20				Straight
CY-35-20NT	20	3.5	4.0	≥ 2.5 & <3.5	Curved 45°
CY-35-24	24	3.5	4.0	≥ 2.5 & <3.5	Straight
CY-35-24NT	24	3.5	4.0	≥ 2.5 & <3.5	Curved 45°
CY-40-14	14	4.0	4.5	≥ 3.5 & <4.0	Straight
CY-40-14NT	14				Curved 45°
CY-40-20	20				Straight	0.017
CY-40-20NT	20				Curved 45°
CY-40-24	24	4.0	4.5	≥ 3.5 & <4.0	Straight
CY-40-24NT	24	4.0	4.5	≥ 3.5 & <4.0	Curved 45°
CY-40-32	32	4.0	4.5	≥ 3.5 & <4.0	Straight
CY-40-32NT	32	4.0	4.5	≥ 3.5 & <4.0	Curved 45°
CY-50-14	14	5.0	5.5	≥ 4.0 & ≤ 4.5	Straight
CY-50-14NT	14				Curved 45°
CY-50-20	20				Straight	0.017
CY-50-20NT	20				Curved 45°
CY-50-24	24	5.0	5.5	≥ 4.0 & ≤ 4.5	Straight
CY-50-24NT	24	5.0	5.5	≥ 4.0 & ≤ 4.5	Curved 45°
CY-50-32	32	5.0	5.5	≥ 4.0 & ≤ 4.5	Straight	0.017
CY-50-32NT	32	5.0	5.5	≥ 4.0 & ≤ 4.5	Curved 45°	0.017

Case Reports

Check out the case reports of CYLLENE Intracranial Bridging Stent!

DISCLAIMER

All Keuro MedTech products are to be used exclusively by trained medical professionals.

Please consult the Instructions for Use for all indications, contraindications, warnings, cautions as well as possible adverse effects.

Products may not be approved in regions and countries. Please consult info@keuromedtech.com for your regions and countries.
